ThingsLog 4G Low Power Data Logger
Configurable 4G IoT data logger for pulse and analog reading
ThingsLog’s 4G low power data loggers enable reliable remote data logging and electronic meter reading across various industries. Designed for efficiency and long battery life, our devices support water metering, pressure monitoring, tank level measurement, temperature tracking, and electricity consumption monitoring. Whether you need a remote sensor solution or a smart meter reader, our 4G low power data logger delivers accurate, real-time insights to optimize operations and reduce costs.
Managed through ThingsLog IoT Platform.
Global support for 4G frequencies
2 pulse metering inputs
4 analog inputs 0-3V or 4-20mA
i2C bus
16 bit ADC / precision 0.01%
Option for 24-bit Sigma/Delta ADC
Sensor power supply - 3.6V or 12V
Relay outputs
Alarm inputs
GNSS Option
EEPROM Option
Wide range of supported IOT sensors
CE cerifified
Power supply options: 3.6V LiS02 battery, external power supply or embedded solar PV panel
Battery life of 20000 transmissions in low power mode
Configurable metering and transmission
Over-the-Air reconfiguration
Firmware update
IP68 level of protection
Optional Global network support with built in 1NCE SIM
Data presented on ThingsLog platform
MQTT/TLS support
Possibility for REST API integration
Benefits
Low power
Just 6uA in sleeping mode! Able to work long years on batteries!
Certified
CE certified – comply with European Safety, LVD, and EMC directives!
Versatile
Low Power, solar panel powered or electricity powered data logger with multiple configuration options.
Configurable over the air
Supports remote configuration over the AiR through the ThingsLog platform!
Documented
Well-documented product used by many utilities and enterprises!
Global Mobile offering
Comes with GPRS/4G global roaming SIM card
Well protected
Has IP68 level of moisture and dust protection
Upgradable
Stick to your current firmware or upgrade to a newer more capable version.
Alarms in low power
Instant alarms in low-power mode in case of abnormal consumption, leak, high/low value, etc.
How ThingsLog Delivers Flexible, Customizable Monitoring Systems
We work “order to configure”, which means that we customize our loggers to your use case.
This makes our delivery time 35 working days for 100+ devices and 10 working days for a sample delivery.
More information on how we deliver and how we price is available here.
ThingsLog Platform
ThingsLog data loggers standardly work with ThingsLog Cloud platform that takes care of device and data management.
Read more about the platform here.
